FRONT DOOR
SM 3-3 B291/B295/B296/B297
Replacement
Adjustment
3.3 FRONT DOOR
1. Open front door.
2. To remove the front door, remove left pin [A], and right pin [B].
B195R901.WMF
[A]
[B]
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
