PRINTED CIRCUIT BOARDS
SM 3-85 B291/B295/B296/B297
Replacement
Adjustment
IOB DIP Switch Settings (SW101)
1. The position of SW 1 determines the engine speed. This switch should be UP
(ON) for the B291/B296 (35 cpm) or DOWN (OFF) for the B295/B297 (45 cpm)
NOTE: Move a switch UP to ON or DOWN to OFF.
2. SW 2, 3, 4, and 5 should all be DOWN (OFF). Do not change these settings.
This information is only for reference:
SW If set to ON
2 Switches off jam detection.
3 Engine program recovery.
4 Print output for debugging.
5 Switches off SC detection.
3. SW 6, 7, 8 should be set for the area where the machine is used and serviced.
6 7 8 Location
OFF OFF OFF Japan
ON OFF OFF North America
OFF ON OFF Europe
ON OFF ON Taiwan
ON ON OFF Asia
OFF ON ON Korea
ON ON ON Not used
ON: Up
OFF: Down
