Ricoh B291 - B291;B295;B296;B297; Default Chapter; Table of Contents

SM i B291/B295/B296/B297
B291/B295/B296/B297
TABLE OF CONTENTS
INSTALLATION PROCEDURE
1. INSTALLATION PROCEDURE.................................................... 1-1
1.1 INSTALLATION REQUIREMENTS ...........................................................1-1
1.1.1 ENVIRONMENT ...............................................................................1-2
1.1.2 MACHINE LEVEL.............................................................................1-2
1.1.3 MINIMUM SPACE REQUIREMENTS...............................................1-3
1.1.4 POWER REQUIREMENTS ..............................................................1-5
1.2 INSTALLATION FLOW CHART ................................................................1-6
1.3 MAIN MACHINE INSTALLATION..............................................................1-7
1.3.1 ACCESSORY CHECK......................................................................1-7
1.3.2 INSTALLATION PROCEDURE ........................................................1-8
Development Unit and PCU................................................................1-10
Toner Bottle ........................................................................................1-13
Paper Trays ........................................................................................1-14
Initialize TD Sensor and Developer.....................................................1-16
Set Paper Size for Paper Trays ..........................................................1-17
Electrical Total Counter.......................................................................1-18
HDD Caution Decal.............................................................................1-18
Exposure Glass Cleaner .....................................................................1-19
1.4 PAPER TRAY UNIT INSTALLATION (B542) ..........................................1-20
1.4.1 ACCESSORY CHECK....................................................................1-20
1.4.2 PAPER TRAY UNIT INSTALLATION PROCEDURE .....................1-21
1.5 1-BIN TRAY UNIT INSTALLATION (B544) .............................................1-25
1.5.1 ACCESSORY CHECK....................................................................1-25
1.5.2 1-BIN TRAY INSTALLATION PROCEDURE..................................1-26
1.6 BRIDGE UNIT INSTALLATION (B538) ...................................................1-32
1.6.1 ACCESSORY CHECK....................................................................1-32
1.6.2 BRIDGE UNIT INSTALLATION PROCEDURE ..............................1-33
1.7 TWO-TRAY FINISHER INSTALLATION (B545)......................................1-35
1.7.1 ACCESSORY CHECK....................................................................1-35
1.7.2 TWO-TRAY FINISHER INSTALLATION PROCEDURE.................1-36
1.8 PUNCH UNIT INSTALLATION (B377) ....................................................1-39
1.8.1 ACCESSORY CHECK....................................................................1-39
1.8.2 PUNCH UNIT INSTALLATION PROCEDURE ...............................1-40
1.9 ARDF INSTALLATION (B714).................................................................1-43
1.9.1 ACCESSORY CHECK....................................................................1-43
1.9.2 ARDF INSTALLATION PROCEDURE............................................1-44
1.9.3 ARDF SKEW ADJUSTMENT .........................................................1-48
1.10 LCT INSTALLATION (B543)..................................................................1-49
1.10.1 ACCESSORY CHECK..................................................................1-49
1.10.2 LCT INSTALLATION PROCEDURE.............................................1-50
