PAPER FEED
B291/B295/B296/B297 3-54 SM
14. Guide plate [A] and registration roller [B] (spring x1, # x 1)
15. Registration guide plate [C] (! x2, " x1)
16. Sensor bracket [D] (! x1)
17. Registration sensor [E] (! x1, " x1)
B195R983.WMF
B195R984.WMF
[A]
[B]
[C]
[D]
[E]
To Next Page
