DEDICATED TRANSMISSION PARAMETERS
B779 98 SM
Switch 03
No FUNCTION COMMENTS
5
Compression modes available
in transmit mode
0: MH only
1: Disabled
This bit determines the capabilities that are informed
to the other terminal during transmission.
If the setting is “Disabled”, the bit switch setting is
used.
6
7
ECM during transmission
Bit 7 Bit 6 Setting
0 0 Off
0 1 On
1 0 Not used
1 1 Disabled
For example, if ECM is switched on but is not
wanted when sending to a particular terminal, use
the (0, 0) setting.
Note that V.8/V.34 protocol and JBIG compression
are automatically disabled if ECM is disabled.
If the setting is “Disabled”, the bit switch setting is
used.
Switch 04 - Not used (do not change the settings)
Switch 05 - Not used (do not change the settings)
Switch 06 - Not used (do not change the settings)
Switch 07 - Not used (do not change the settings)
Switch 08 - Not used (do not change the settings)
Switch 09 - Not used (do not change the settings)
