532 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Appendix C EtherNet/IP Information
Table 568 - Control Supervisor Object Instance 1 Attributes
The following common services are implemented for the Control Supervisor
Object.
Table 569 - Control Supervisor Object Common Services
Overload Object — CLASS CODE 0x002c
No class attributes are supported for the Overload Object.
A single instance (instance 1) of the Overload Object is supported.
Table 570 - Overload Object Instance 1 Attributes
The following common services are implemented for the Overload Object.
Table 571 - Overload Object Common Services
Base Energy Object — CLASS CODE 0x004E
The following class attributes are supported for the Base Energy Object.
Attribute ID Access Rule Name Data Type Value
10 Get Tripped BOOL
0 = No Fault present
1 = Fault Latched
11 Get Warning BOOL
0 = No Warning present
1 = Warning present (not latched)
12 Get/Set Fault Reset BOOL
0->1 = Trip Reset
otherwise no action
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
4 Get/Set Trip Class USINT 5…30
5 Get Average Current INT xxx.x Amps (tenths of amps)
6 Get %Phase Imbal USINT xxx% FLA
7 Get % Thermal Utilized USINT xxx% FLA
8 Get Current L1 INT xxx.x Amps (tenths of amps)
9 Get Current L2 INT xxx.x Amps (tenths of amps)
10 Get Current L3 INT xxx.x Amps (tenths of amps)
11 Get GF Current INT 0.00 – 12.75 Amps
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
