Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 87
System Operation and Configuration Chapter 4
Table 56 - Screen 1 - Parameter 2 (Parameter 429)
User-defined Screen 2
User-defined Screen 2 – Parameter 1
User-defined Screen 2 - Parameter 1 (Parameter 430) is the E300 parameter
number to display for the first parameter in user-defined screen 2. You can select
one of the 560 available E300 Electronic Overload Relay parameters.
Table 57 - Screen 2 - Parameter 1 (Parameter 430)
User-defined Screen 2 – Parameter 2
User-defined Screen 2 - Parameter 2 (Parameter 431) is the E300 parameter
number to display for the second parameter in user-defined screen 2. You can
select one of the 560 available E300 Electronic Overload Relay parameters.
Table 58 - Screen 2 - Parameter 2 (Parameter 431)
Default Value 50
Minimum Value 0
Maximum Value 560
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 2
Minimum Value 0
Maximum Value 560
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 3
Minimum Value 0
Maximum Value 560
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
