306 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 8 Metering and Diagnostics
Time to Trip
When the measured motor current exceeds the trip rating of the E300 Electronic
Overload Relay, Overload Time to Trip (Parameter 2) indicates the estimated
time remaining before an overload trip occurs. When the measured current is
below the trip rating, the Overload Time to Trip value is reported as 9,999
seconds.
Table 356 - Overload Time to Trip (Parameter 2)
Time To Reset
After an overload trip, the E300 Electronic Overload Relay reports the time
remaining until the device can be reset through Overload Time to Reset
(Parameter 3). When the % Thermal Capacity Utilized value falls to or below the
Overload Reset Level (Parameter 174), the Overload Time to Reset value
indicates zero until the overload trip is reset. After an overload trip is reset, the
Overload Time to Reset value is reported as 0 seconds.
Table 357 - Overload Time to Reset (Parameter 3)
Default Value 9999
Minimum Value 0
Maximum Value 9999
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units Seconds
Default Value 0
Minimum Value 0
Maximum Value 9999
Parameter Type UINT
