310 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 8 Metering and Diagnostics
Current Warning Status
Current Warning Status (Parameter 10) reports the status of the current-based
protective warning functions.
Table 362 - Current Warning Status (Parameter 10)
Voltage Warning Status
Voltage Warning Status (Parameter 11) reports the status of the control-based
protective warning functions.
Table 363 - Voltage Warning Status (Parameter 11)
Bit
1514131211109876543210 Function
XOverload Warning
Reserved
X Ground Fault Warning
Reserved
XJam Warning
XUnderload Warning
X Current Imbalance Warning
X L1 Under Current Warning
X L2 Under Current Warning
X L3 Under Current Warning
X L1 Over Current Warning
X L2 Over Current Warning
X L3 Over Current Warning
X L1 Line Loss Warning
X L2 Line Loss Warning
X L3 Line Loss Warning
Bit
1514131211109876543210 Function
X Under Voltage Warning
X Over Voltage Warning
X Voltage Imbalance Warning
X Phase Rotation Mismatch Warning
X Under Frequency Warning
XOver Frequency Warning
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
