Appendix A Specifications
Environmental Specifications
➊ Current ratings must be derated at altitudes greater than 2000 m
➋ Temperature rating based on 120V AC control module with 1 A going through relays 0, 1, and 2.
➌ Temperature rating based on 24V DC control module with four digital inputs active and 0.2 A going through
relays 0, 1, and 2.
➍ Temperature rating based on 120V AC or 240V AC control module with 5A going through relays 0, 1, and 2.
NOTE: The E300 Electronic Overload Relay expansion power supplies (Cat.
Nos. 193-EXP-PS-AC and 193-EXP-PS-DC) surrounding air temperature must
not exceed 55 °C (131 °F).
Table 515 - Temperature Derating
Table 513 - Expansion Power Supply Modules
Expansion Power Supply Modules 193-EXP-PS-AC
Rated Operational Voltage (U
e
): 100…250V AC
Rated Insulation Voltage (U
i
): 2640Vrms for 1s
Rated Impulse Withstand Voltage (U
imp
): 4 kV
Conditional Short Circuit Current: N/A
Protection Against Short Circuits: N/A
Utilization Category: N/A
Pollution Degree: 3
Table 514 - Environmental Specifications
Ambient Temperature
Storage
Operating
(Open)
(Enclosed)
–40…+85 C (–40…+185 F)
–20…+55 C (–4…+131 F)➋➌
–20…+40 C (–4…+104 F)➌➍
Humidity
Operating
Damp Heat – Steady State (per IEC 68-2-3)
Damp Heat – Cyclic (per IEC 68-2-30)
5…95% Non-condensing
92% r.h., 40 C (104 F), 56 days
93% r.h., 25 C/40 C (77 F/104 F), 21 Cycles
Cooling Method Natural Convection
Vibration (per IEC 68-2-6) 2.5G operating, 5 G non-operating
Shock (per IEC 68-2-27) 30 G
Maximum Altitude 2000 m ➊
Pollution Environment Pollution Degree 3
Terminal Marking EN 50012
Degree of Protection IP20
Control Module
Voltage
Relay 0
Current
Relay 1
Current
Relay 2
Current
Number of
Digital Inputs
Active
Operating Temperature
Range
Open Application
120/240V AC
1.0 A 1.0 A 1.0 A 4 -20…+55 °C (-4…+131 °F)
5.0 A 1.0 A 1.0 A 4 -20…+50 °C (-4…+122 °F)
24V DC
0.2 A 0.2 A 0.2 A 4 -20…+55 °C (-4…+131 °F)
0.2 A 0.2 A 0.2 A 6 -20…+50 °C (-4…+122 °F)
5.0 A 1.0 A 1.0 A 6 -20…+30 °C (-4…+86 °F)
Enclosed
Application
120/240V AC 5.0 A 5.0 A 5.0 A 4 -20…+40 °C (-4…+104 °F)
24V DC
0.2 A 0.2 A 0.2 A 4 -20…+40 °C (-4…+104 °F)
5.0 A 1.0 A 1.0 A 6 -20…+30 °C (-4…+86 °F)
