Chapter 8 Metering and Diagnostics
Operator Station Status
Operator Station Status (Parameter 19) reports the state of the E300 Electronic
Overload Relay Operator Station input buttons and output LEDs.
Table 369 - Operator Station Status (Parameter 19)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
XOperation Station I
XOperation Station II
XOperation Station Local Remote
XOperation Station O
XOperation Station Reset
Reserved
Reserved
Reserved
XOperation Station I LED
X Operation Station II LED
X Operation Station Local LED
X Operation Station Remote LED
XOperation Station O LED
Reserved
Reserved
Reserved
