Chapter 4 System Operation and Configuration
Enable Option Match Protection Warning (Parameter 192)
To enable the E300 Electronic Overload Relay’s Option Match feature to cause a
warning in the event of an option mismatch, place a (1) in bit position 8 of
Parameter 192 (Control Warning Enable). You can select the specific option
match features to cause a warning in Parameter 233 (Option Match Action).
Table 24 - Enable Option Match Protection Warning Bit Function Detail— Control Warning
Enable (Parameter 192)
Control Module Type (Parameter 221)
The E300 Electronic Overload Relay offers six different control modules. Place
the value of the expected control module into Parameter 221. A value of (0)
disables the Option Match feature for the control module.
Table 25 - Control Module Type (Parameter 221)
Bit
1514131211109876543210 Function
Reserved
Reserved
X DeviceLogix Warning Enable
Reserved
Reserved
Reserved
Reserved
Reserved
X Option Match Warning Enable
X Feedback Timeout Warning Enable
X Expansion Bus Warning Enable
X Number Of Starts Warning Enable
X Operating Hours Warning Enable
Reserved
Code Description Control Module Cat. No.
0Ignore —
1 6 Inputs, 24V DC / 3 Relay Outputs 193-EIO-63-24D
2 4 Inputs, 110-120V AC 50/60Hz / 3 Relay Outputs 193-EIO-43-120
3 4 Inputs, 220-240V AC 50/60Hz / 3 Relay Outputs 193-EIO-43-240
4 4 Inputs, 24V DC / 2 Relay Outputs / External Ground Fault / PTC 193-EIOGP-42-24D
5 2 Inputs, 110-120V AC 50/60Hz / 2 Relay Outputs / External Ground Fault / PTC 193-EIOGP-22-120
6 2 Inputs, 220-240V AC 50/60Hz / 2 Relay Outputs / External Ground Fault / PTC 193-EIOGP-22-240
