518 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Appendix C EtherNet/IP Information
Instance 120 - Configuration Assembly Revision 1
The following table shows Attribute 3 Format and Attribute 2 Member List for
revision 1 of the assembly. This is a stripped down simple version of a config
assembly.
Table 538 - Instance 120 — Configuration Assembly
Instance 144 – Default Consumed Assembly
Table 539 - Instance 144 – Default Consumed Assembly
Instance 198 - Current Diagnostics Produced Assembly
Table 540 - Instance 198 – Current Diagnostics Produced Assembly
INTDINT1514131211109876543210Size (bits)Param
0
0
ConfigAssyRev = 1 Reserved 16 1002
1Reserved 16 N/A
2
1FLASetting 32 171
3
4
3
TripClass 8 172
X OLPTCResetMode 1 173
X SingleOrThreePh 1 176
XXXXXX Reserved 6 N/A
5
OLResetLevel 8 174
OLWarningLevel 8175
INTDINT1514131211109876543210Size (bits)Path
0
0
OutputStatus0 16 Param18
1
NetworkStart1 X Symbolic
NetworkStart2 X Symbolic
TripReset X Symbolic
EmergencyStart X Symbolic
RemoteTrip X Symbolic
Reserved X X X N/A
X HMILED1Green Symbolic
X HMILED2Green Symbolic
X HMILED3Green Symbolic
X HMILED3Red Symbolic
X HMILED4Red Symbolic
XXX Reserved N/A
2
1
DLXPtDeviceIn 16 Symbolic
3 DLXAnDeviceIn 16 Symbolic
INTDINT1514131211109876543210Size (bits)Param
0
0 Reserved for Logix 32 1104
1
2
1
DeviceStaus0 16 20
3 DeviceStaus1 16 21
