Rockwell Automation Publication 193-UM015D-EN-P - February 2015 71
System Operation and Configuration Chapter 4
Digital I/O Expansion Module 2 Type (Parameter 226)
The E300 Electronic Overload Relay supports up to four additional Digital I/O
expansion modules. This parameter configures the Option Match feature for the
Digital I/O expansion module set to Digital Module 2. There are three different
types of Digital I/O expansion modules. Place the value of the expected Digital
I/O expansion module set to Digital Module 2 into Parameter 226. A value of (0)
disables the Option Match feature for this Digital I/O expansion module. A
value of (1),“No Digital I/O Expansion Module”, makes the Digital I/O expansion
module set to Digital Module 2 not allowed on the Expansion Bus and prevents
you from connecting a Digital I/O expansion module set to Digital Module 2 to
the E300 Electronic Overload Relay system.
Table 30 - Digital I/O Expansion Module 2 Type (Parameter 226)
Digital I/O Expansion Module 3 Type (Parameter 227)
The E300 Electronic Overload Relay supports up to four additional Digital I/O
expansion modules. This parameter configures the Option Match feature for the
Digital I/O expansion module set to Digital Module 3. There are three different
types of Digital I/O expansion modules. Place the value of the expected Digital
I/O expansion module set to Digital Module 3 into Parameter 227. A value of (0)
disables the Option Match feature for this Digital I/O expansion module. A
value of (1),“No Digital I/O Expansion Module”, makes the Digital I/O expansion
module set to Digital Module 3 not allowed on the Expansion Bus and prevents
you from connecting a Digital I/O expansion module set to Digital Module 3 to
the E300 Electronic Overload Relay system.
Table 31 - Digital I/O Expansion Module 3 Type (Parameter 227)
Digital I/O Expansion Module 4 Type (Parameter 228)
The E300 Electronic Overload Relay supports up to four additional Digital I/O
expansion modules. This parameter configures the Option Match feature for the
Code Description Digital I/O Expansion Module Cat. No.
0Ignore —
1
No Digital I/O Expansion Module (Digital I/O Expansion
Module Not Allowed)
—
2 4 Inputs, 24V DC / 2 Relay Outputs 193-EXP-DIO-42-24D
3 4 Inputs, 110-120V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-120
4 4 Inputs, 220-240V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-240
Code Description Digital I/O Expansion Module Cat. No.
0Ignore —
1
No Digital I/O Expansion Module (Digital I/O Expansion
Module Not Allowed)
—
2 4 Inputs, 24V DC / 2 Relay Outputs 193-EXP-DIO-42-24D
3 4 Inputs, 110-120V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-120
4 4 Inputs, 220-240V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-240
