Rockwell Automation Publication 193-UM015D-EN-P - February 2015 503
Appendix C
EtherNet/IP Information
Common Industrial Protocol
(CIP) Objects
The E300 Electronic Overload Relay’s EtherNet/IP Communication Module
supports the following Common Industrial Protocol (CIP).
Table 521 - CIP Object Classes
Class Object
0x0001 Identity
0x0002 Message Router
0x0003 DeviceNet
0x0004 Assembly
0x0005 Connection
0x0008 Discrete Input Point
0x0009 Discrete Output Point
0x000A Analog Input Point
0x000F Parameter Object
0x0010 Parameter Group Object
0x001E Discrete Output Group
0x0029 Control Supervisor
0x002B Acknowledge Handler
0x002C Overload Object
0x004E Base Energy Object
0x004F Electrical Energy Object
0x008B Wall Clock Time Object
0x0097 DPI Fault Object
0x0098 DPI Warning Object
0x00C2 MCC Object
