Rockwell Automation Publication 193-UM015D-EN-P - February 2015 541
EtherNet/IP Information Appendix C
DPI Warning Object — CLASS CODE 0x0098
This object provides access to warning information within the device.
The following class attributes are supported:
Table 586 - DPI Warning Object Class Attributes
Four instances of the DPI Warning Object are supported.
Table 587 - DPI Warning Object Instance Attributes
97 Trip97
98 HardwareFltTrip A hardware fault condition was detected
99 Trip99
Attribute ID Access Rule Name Data Type Value
1 Get Class Revision UINT 1
2 Get Number of Instances UINT 8
3 Get/Set Warning Cmd Write USINT 0=NOP 2=Clear Queue
4 Get Warning Instance Read UINT
The instance of the Warning Queue
Entry containing information about
the most recent warning
6 Get Number of Recorded Faults UINT
The number of Warning recorded in
the Warning Queue
Attribute ID Access Rule Name Data Type Value
0Get
Full / All Info Struct of:
Warning Code UINT See Warning Table below
Warning Source Struct of:
DPI Port Number USINT 0
Device Object
Instance
USINT 0x2c
Warning Text BYTE[16] See Table 589
Warning Time
Stamp
Struct of:
Timer Value ULINT
Timer Descriptor WORD
Help Object
Instance
UINT
Fault Data
1Get
Basic Info Struct of:
Warning Code UINT See Table 589
Warning Source Struct of:
DPI Port Number USINT 0
Device Object
Instance
USINT 0x2C
Warning Time
Stamp
Struct of:
Timer Value ULINT
Timer Descriptor WORD
3 Get Help Text STRING See Table 589
Fault Code Fault Text Help Text
