Chapter 8 Metering and Diagnostics
Table 463 - Analog Module 1 Status (Parameter 123)
Analog Module 2
Analog Module 2 – Input Channel 00
Analog Module 2 – Input Channel 00 (Parameter 114) reports the monitored
value of Analog Module 2 – Input Channel 00.
Table 464 - Analog Module 2 – Input Channel 00 (Parameter 114)
Analog Module 2 – Input Channel 01
Analog Module 2 – Input Channel 01 (Parameter 115) reports the monitored
value of Analog Module 2 – Input Channel 01.
Bit
Function
1514131211109876543210
XInput Channel 00 Open Circuit
XInput Channel 00 Over Range
XInput Channel 00 Under Range
XInput Channel 01 Open Circuit
XInput Channel 01 Over Range
XInput Channel 01 Under Range
XInput Channel 02 Open Circuit
XInput Channel 02 Over Range
XInput Channel 02 Under Range
XOutput Channel 00 Open Circuit
X
Output Channel 00 Hold Last State
Mode Active
XOutput Channel 00 Over Range
XOutput Channel 00 Under Range
XAnalog Module Configured
X
Analog Module Warning (Module
Number Dial Changed)
XAnalog Module Faulted
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
