308 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 8 Metering and Diagnostics
Voltage Trip Status
Voltage Trip Status (Parameter 5) reports the status of the voltage-based
protective trip functions.
Table 359 - Voltage Trip Status (Parameter 5)
Bit
1514131211109876543210 Function
X Under Voltage Trip
X Over Voltage Trip
X Voltage Imbalance Trip
X Phase Rotation Mismatch Trip
X Under Frequency Trip
XOver Frequency Trip
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
