276 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 333 - Analog Module 2 – Channel 02 Warning Level (Parameter 494)
Analog Module 3
The E300 Analog I/O Expansion Module scans up to three analog signals. An
over level trip or warning can be configured for each input channel.
Analog Module 3 – Channel 00 Over Level Trip
The E300 Electronic Overload Relay trips with an Analog Module 3 – Channel
00 Over Level Trip indication if:
No trip currently exists
Analog Module 3 – Channel 00 Over Level Trip is enabled
The measured analog input signal is greater than the Analog Module 3
Channel 00 Trip Level for a time period greater than the Analog Module 3
– Channel 00 Over Level Trip Delay.
If the E300 Electronic Overload Relay trips on an Analog Module 3 – Channel
00 Over Level, the:
TRIP/WARN LED status indicator flashes a red 4-long / 7-short blink
pattern
Bit 6 in Analog Trip Status (Parameter 8) sets to 1
Bit 0 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Trip Relay open
Any relay outputs configured as a Control Relay open
Any relay outputs configured as a Trip Alarm close
Any relay outputs configured as a Normal Relay are placed in their
Protection Fault state (if so programmed)
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
