Metering and Diagnostics Chapter 8
Current Trip Status
Current Trip Status (Parameter 4) reports the status of the current-based
protective trip functions.
Table 358 - Current Trip Status (Parameter 4)
Bit
1514131211109876543210 Function
XOverload Trip
X Phase Loss Trip
X Ground Fault Current Trip
X Stall Trip
X Jam Trip
X Underload Trip
X Current Imbalance Trip
X L1 Under Current Trip
X L2 Under Current Trip
X L3 Under Current Trip
X L1 Over Current Trip
X L2 Over Current Trip
X L3 Over Current Trip
X L1 Line Loss Trip
X L2 Line Loss Trip
X L3 Line Loss Trip
