Chapter 8 Metering and Diagnostics
Table 375 - Operator Station ID (Parameter 25)
Expansion Digital Module ID
Expansion Digital Module ID (Parameter 26) identifies which specific
Expansion Digital Modules are present on the Expansion Bus of the E300
Electronic Overload Relay system.
Table 376 - Expansion Digital Module ID (Parameter 26)
Operating Time
Operating Time (Parameter 28) represents the number hours that a motor has
been running. This value can be reset to zero using the Clear Command
(Parameter 165) function Clear Operating Statistics.
Default Value 0
Range
0 = Unknown
1 = None
2 = 193-EOS-SCS
3 = 193-EOS-SDS
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
000None
Digital Module 1
0 1 0 193-EXP-DIO-42-24D
0 1 1 193-EXP-DIO-42-120
1 0 0 193-EXP-DIO-42-240
000 None
Digital Module 2
0 1 0 193-EXP-DIO-42-24D
0 1 1 193-EXP-DIO-42-120
1 0 0 193-EXP-DIO-42-240
000 None
Digital Module 3
0 1 0 193-EXP-DIO-42-24D
0 1 1 193-EXP-DIO-42-120
1 0 0 193-EXP-DIO-42-240
000 None
Digital Module 4
0 1 0 193-EXP-DIO-42-24D
0 1 1 193-EXP-DIO-42-120
1 0 0 193-EXP-DIO-42-240
