Chapter 2 Installation and Wiring
Table 9 - Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with Bul. 100-C IEC
contactors that are protected by Bul. 140U-D circuit breakers
Table 10 - High Fault Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with
Bul. 500 line NEMA contactors that are protected by fuses
Fuse Coordination
The following tables list Type I and Type II Fuse Coordination when used with
Bulletin 100-C and 100-D and Bulletin 500 NEMA Size 00… 2 Contactors.
Overload Relay with
Sensing Module Cat. No.
Contactor Cat. No. Max. Starter FLC[A]
Max. Available Fault
Current [A]
Max. Voltage [V]
Max. Circuit Breaker
Cat. No. 140U-D6D3-
193-ESM-___-30A-C23
100-C09 9
65,000 480Y/277V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
193-ESM-___-30A-C23
100-C09 9
35,000 600Y/347V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
193-ESM-___-30A-C23
100-C09 9
5,000 600Y/347V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
Overload Relay with Sensing Module
Cat. No.
Contactor Size Max. Starter FLC [A]
Max. Available Fault
Current [A]
Max. Voltage
[V]
Max. UL Fuse [A]
RJ
592-ESM-___-30A-S2 00 9
100,000
600 — 20
592-ESM-___-30A-S2 0 18
240 30 30
600 30 30
592-ESM-___-30A-S2 1 27
240 60 100
600 30 50
592-ESM-___-60A-S2 2 45
240 100 200
600 60 100
592-ESM-___-100A-S3 3 90
240 200 350
600 100 200
ATTENTION: Select the motor branch circuit protection that complies with the
NEC and any other governing regional or local codes.

Rockwell Automation Allen-Bradley E300 Specifications

General

Category	Electronic Overload Relay
Control Voltage	24V AC/DC
Ambient Temperature	-20 to 60°C
Voltage	690 V AC max
Communication Protocol	EtherNet/IP, DeviceNet, Modbus RTU
Protection Type	Overload, Phase Loss, Ground Fault, Jam, Undercurrent
Mounting Type	DIN Rail
Trip Class	10, 20, 30
Display	LCD
Standards Compliance	UL, CE
