334 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 8 Metering and Diagnostics
Table 417 - L1 Reactive Power (Parameter 68)
L2 Reactive Power
L2 Reactive Power (Parameter 69) reports the reactive power for line 2 in kVAR
or MVAR depending on the configuration value for Power Scale (Parameter
377). When Voltage Mode (Parameter 352) is set to any Delta base setting, L2
Reactive Power is set to 0.
Table 418 - L2 Reactive Power (Parameter 69)
L3 Reactive Power
L3 Reactive Power (Parameter 70) reports the reactive power for line 3 in kVAR
or MVAR depending on the configuration value for Power Scale (Parameter
377). When Voltage Mode (Parameter 352) is set to any Delta base setting, L3
Reactive Power is set to 0. When Single or Three Phase (Parameter 176) is set to
Single Phase, L3 Reactive Power is set to 0.
Table 419 - L3 Reactive Power (Parameter 70)
Total Reactive Power
Total Reactive Power (Parameter 71) reports the total Reactive power of the
monitored power conductors in kVAR or MVAR depending on the
Default Value 0.000
Minimum Value -2000000.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVAR or MVAR
Default Value 0.000
Minimum Value -2000000.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVAR or MVAR
Default Value 0.000
Minimum Value -2000000.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVAR or MVAR
