Chapter 2 Installation and Wiring
Communication Module to
Control Module Assembly
You can connect any E300 Communication Module to any E300 Control
Module. The illustrations below show the steps required to make this
connection.
Figure 7 - Communication Module to Control Module Assembly
1
3
2
