Appendix A
Specifications
Electrical Specifications
Table 506 - Motor/Load Ratings
Terminals 1/L1, 3/L2, 5/L3, 2/T1, 4/T2, 6/T3
Rated Insulation Voltage (U
i
) 690V AC
Rated Operating Voltage (U
e
)
IEC:
UL:
690V AC
600V AC
Rated Impulse Voltage (U
imp
)6 kV
Rated Operating Current (I
e
) See Catalog Number Explanation
Rated Frequency 45...65 Hz
Short Circuit Ratings See Short-Circuit Ratings on page 44
Number of Poles 3
Application Single-phase or Three-phase
Table 507 - Power Supply Ratings
Rated Supply Voltage (U
s
) 24V DC 120V AC 240V AC
Operating Range 11…30V DC 85…132V AC 159…265V AC
Maximum Inrush Current 3 A for 30 ms 10 A for 1 ms 8 A for 3 ms
Maximum Power Consumption
E300:
E300 with expansion:
6 W
8 W
Maximum Power Interruption Time
V
min
:
V
max
:
5 ms
5 ms
10 ms
10 ms
10 ms
10 ms
Table 508 - Output Relay Ratings (Control Module and Expansion Digital Module)
Terminals
Relay 0:
Relay 1:
Relay 2:
R03/R04
R13/R14
R23/R24
Type of Contacts
Form A
SPST - NO
Rated Thermal Current (I
the
)5 A
Rated Insulation Voltage (U
i
) 300V AC
Rated Operating Voltage (U
e
) 250V AC
Rated Operating Current (I
e
)
3 A (@120V AC), 1.5 A (@240V AC)
0.25 A (@110V DC), 0.1 A (@220V DC)
Minimum Operating Current 10 mA @ 5V DC
Rating Designation B300
Utilization Category AC-15
Resistive Load Rating (p.f. = 1.0)
5 A, 250V AC
5 A, 30V DC
