90 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 4 System Operation and Configuration
Analog I/O Expansion
Modules
The E300 Electronic Overload Relay supports up to four Analog I/O Expansion
Modules on the E300 Expansion Bus. The E300 Analog Expansion Module has
three independent universal inputs and one analog output.
Analog Input Channels
The universal analog inputs can accept the following analog signals:
• Current
– 4…20 mA
– 0…20 mA
• Vo l t ag e
– 0…10V DC
– 1…5V DC
– 0…5V DC
• 2-Wire or 3-Wire RTD Sensors
– 100 Ω, 200 Ω, 500 Ω, 1000 Ω Pt 385
– 100 Ω, 200 Ω, 500 Ω, 1000 Ω Pt 3916
– 10 Ω Cu 426
– 100 Ω Ni 618
– 120 Ω Ni 672
– 604Ω NiFe 518
• Resistance
– 0…150 Ω
– 0…750 Ω
– 0…3000 Ω
– 0…6000 Ω (PTC and NTC Sensors)
The analog inputs can report data in four different formats. Table 63 through
Table 66
display the data ranges for all of the available analog input types for the
four available data formats.
Table 63 - Analog Input Data Format for Current Input Type
Input Range Input Value Condition
Engineering
Units
Engineering
Units x 10
Raw /
Proportional
PID
4…20 mA
21.00 mA High Limit 21000 2100 32767 17407
20.00 mA High Range 20000 2000 32767 16383
4.00 mA Low Range 4000 400 -32768 0
3.00 mA Low Limit 3000 300 -32768 -1024
0…20 mA
21.00 mA High Limit 21000 2100 32767 17202
20.00 mA High Range 20000 2000 32767 16383
0.00 mA Low Range 0 0 -32768 0
0.00 mA Low Limit 0 0 -32768 0
