Chapter 4 System Operation and Configuration
• To ta l Po we r Fa c t o r
• User-defined Value
Table 69 - Analog Output Selection Type
Update Rate
Analog Input Channels
The performance for the input channels of the E300 Analog I/O Expansion
Module is dependent on the filter setting for each channel. The total scan time
for the input channels of the module is determined by adding the conversion time
for all enabled input channels.
Table 70 - Analog Input Channel Conversion Time
Example:
• Channel 00 is configured for a 3-wire RTD and 4 Hz filter (conversion
time = 1024 ms).
• Channel 01 is configured for 17Hz voltage (conversion time = 153 ms).
• Channel 02 is configured for 62Hz current (conversion time = 65 ms).
Output Selection Low Range High Range
Average % FLA 0% 100%
Scaled Average % FLA 0% 200%
% TCU 0% 100%
Ground Fault Current
Internal, 0.50…5.00 A 0.50 A 5.00 A
External, 0.02…0.10 A 0.02 A 0.10 A
External, 0.10…0.50 A 0.10 A 0.50 A
External, 0.20…1.00 A 0.20 A 1.00 A
External, 1.00…5.00 A 1.00 A 5.00 A
Current Imbalance 0% 100%
Average L-L Voltage 0V (PT Primary) V
Voltage Imbalance 0% 100%
Total kW 0 kW (FLA1 x PT Primary x 1.732) V
Total kVAR 5.25V DC (FLA1 x PT Primary x 1.732) V
Total kVA 5.00V DC (FLA1 x PT Primary x 1.732) V
Total Power Factor -50% (Lagging) +50% (Leading)
User-defined Value -32768 32767
Input Type Filter Frequency Conversion Time
Current, Voltage,
2-Wire RTD, Resistance
17 Hz 153 ms
4 Hz 512 ms
62 Hz 65 ms
470 Hz 37 ms
3-Wire RTD
17 Hz 306 ms
4 Hz 1024 ms
62 Hz 130 ms
470 Hz 74 ms
