Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 93
System Operation and Configuration Chapter 4
• Vo l t ag e
– 0…10V DC
– 1…5V DC
– 0…5V DC
The analog outputs can report data as a percent of range. Table 67 and Table 68
display the data ranges for all of the available analog output types.
Table 67 - Analog Output Data Format for Current Output Type
Table 68 - Analog Output Data Format for Voltage Output Type
The analog output can be used to communicate E300 diagnostic information via
an analog signal to distributed control systems, programmable logic controllers,
or panel-mounted analog meters. The analog output can represent one of the
following E300 diagnostic parameters:
• Average %FLA
• %TCU
• Ground Fault Current
• Current Imbalance
• Average L-L Voltage
• Voltage Imbalance
• To ta l kW
• To ta l kVA R
• To ta l kVA
Output Range Output Signal Condition % Range
4…20 mA
21.000 mA High Limit 106.25%
20.000 mA High Range 100.00%
4.000 mA Low Range 0.00%
3.000 mA Low Limit -6.25%
0…20 mA
21.00 mA High Limit 105.00%
20.00 mA High Range 100.00%
0.00 mA Low Range 0.00%
0.00 mA Low Limit 0.00%
Output Range Output Value Condition % Range
0…10 V DC
10.50V DC High Limit 105.00%
10.00V DC High Range 100.00%
0.00V DC Low Range 0.00%
0.00V DC Low Limit 0.00%
1…5 V DC
5.25V DC High Limit 106.25%
5.00V DC High Range 100.00%
1.00V DC Low Range 0.00%
0.50V DC Low Limit -6.25%
0…5 V DC
5.25V DC High Limit 105.00%
5.00V DC High Range 100.00%
0.00V DC Low Range 0.00%
0.00V DC Low Limit 0.00%
