58 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 3 Diagnostic Station
Press to return to the linear list navigation system.
If you do not press any navigation keys for a period that is Defined by Display
Timeout (Parameter 436), then the E300 Diagnostic Station automatically
returns to its programmable display sequence.
System Info
The E300 Diagnostic Station can display firmware revision information, view the
time and date of the E300 virtual clock, and edit the time and date of the E300
virtual clock. To view E300 system information, start the navigation menu by
pressing key. Use the or keys to select System Info and press
.
Use the or keys to view the E300 system information.
To edit the system date or time, press to modify the value. Use the or
keys to select the new value. Press to select the next system value. Press
to save the new system values or press to cancel the modification and
restore the previous system values.
