76 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 4 System Operation and Configuration
Firmware Update Policy
The Firmware Update Policy allows you to update the internal firmware of the
communication module and control module via ControlFlash when the E300
Electronic Overload Relay is in Operation Mode. When this policy is disabled,
firmware updates will return a communications error when the E300 Electronic
Overload Relay is in Operation Mode or Run Mode.
Security Configuration Policy
The Security Configuration Policy allows you to modify the Security Policy of
the E300 Electronic Overload Relay in Operation Mode. When this policy is
disabled, the Security Policy can only be modified when the E300 Electronic
Overload Relay is in Administration Mode.
I/O Assignments
The E300 Electronic Overload Relay has native digital inputs and relay outputs
in the Control Module. This I/O can be assign to dedicated functions. the
following sections list the function assignments for the available Control
Module I/O.
Input Pt00 Assignment (Parameter 196)
Input Pt00 Assignment (Parameter 196) allows you to assign this digital input
for the following functions:
Table 39 - Input Pt00 Assignment (Parameter 196)
Value Assignment Description
0 Normal Function as a digital input
1 Trip Reset Reset the E300 when it is in a tripped state
2 Remote Trip Force the E300 to go into a tripped state
3Activate FLA2
Use the value in FLA2 Setting (Parameter 177) for the current-based protection
algorithms
4 Force Snapshot Force the E300 to update its Snapshot log
5 Emergency Start Issue an Emergency Start command
6 Test Mode Enable Test Mode monitoring
7 L1 Line Loss Arm Activate L1 Line Loss Protection
8 L2 Line Loss Arm Activate L2 Line Loss Protection
9 L3 Line Loss Arm Activate L3 Line Loss Protection
10 L1 L2 Line Loss Arm Activate L1 and L2 Line Loss Protection
11 L2 L3 Line Loss Arm Activate L2 and L3 Line Loss Protection
12 L1 L3 Line Loss Arm Activate L1 and L3 Line Loss Protection
13 L1 L2 L3 Line Loss Arm Activate L1, L2, and L3 Line Loss Protection
