206 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 250 - Power Trip Status (Parameter 6)
Table 251 - Power Warning Status (Parameter 12)
Real Power (kW) Protection
The E300 Electronic Overload Relay has the capability to help protect against
real power (kW) for specific applications that require the monitoring of both
voltage and current. You can help protect or issue a warning ifthe real power
(kW) consumption of an electric motor is either too high or too low.
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
XUnder kW Trip
X Over kW Trip
X Under kVAR Consumed Trip
X Over kVAR Consumed Trip
X Under kVAR Generated Trip
X Over kVAR Generated Trip
X Under kVA Trip
X Over kVA Trip
X Under PF Lagging Trip
X Over PF Lagging Trip
X Under PF Leading Trip
X Over PF Leading Trip
Reserved
Reserved
Reserved
Reserved
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
XUnder kW Warning
X Over kW Warning
X Under kVAR Consumed Warning
X Over kVAR Consumed Warning
X Under kVAR Generated Warning
X Over kVAR Generated Warning
X Under kVA Warning
X Over kVA Warning
X Under PF Lagging Warning
X Over PF Lagging Warning
X Under PF Leading Warning
X Over PF Leading Warning
Reserved
Reserved
Reserved
Reserved
