Protective Trip and Warning Functions Chapter 6
Power Trip Enable (Parameter 185) and Power Warning Enable (Parameter 191)
are used to enable the respective power-based protective trip and warning
functions.
Table 248 - Power Trip Enable (Parameter 185)
Table 249 - Power Warning Enable (Parameter 191)
Power Trip Status (Parameter 6) and Power Warning Status (Parameter 12) are
used to view the status of the respective power-based protective trip and warning
functions.
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Under kW Trip
X
Over kW Trip
X
Under kVAR Consumed Trip
X
Over kVAR Consumed Trip
X
Under kVAR Generated Trip
X
Over kVAR Generated Trip
X
Under kVA Trip
X
Over kVA Trip
X
Under PF Lagging Trip
X
Over PF Lagging Trip
X
Under PF Leading Trip
X
Over PF Leading Trip
Reserved
Reserved
Reserved
Reserved
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
XUnder kW Warning
X Over kW Warning
X Under kVAR Consumed Warning
X Over kVAR Consumed Warning
X Under kVAR Generated Warning
X Over kVAR Generated Warning
X Under kVA Warning
X Over kVA Warning
X Under PF Lagging Warning
X
Over PF Lagging Warning
X
Under PF Leading Warning
X
Over PF Leading Warning
Reserved
Reserved
Reserved
Reserved
