Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 369
Metering and Diagnostics Chapter 8
Table 487 - Analog Warning History Mask (Parameter 149)
Trip Snapshot
Trip Snapshot L1-L2 Voltage
Trip Snapshot L1-L2 Voltage (Parameter 156) reports the voltage in volts in
reference to the T1 and T2 power terminals of the E300 Electronic Overload
Relay Sensing Module at the time of the most recent trip event.
Table 488 - Trip Snapshot L1-L2 Voltage (Parameter 156)
Trip Snapshot L2-L3 Voltage
Trip Snapshot L2-L3 Voltage (Parameter 157) reports the voltage in volts in
reference to the T2 and T3 power terminals of the E300 Electronic Overload
Relay Sensing Module at the time of the most recent trip event.
Table 489 - Trip Snapshot L2-L3 Voltage (Parameter 157)
Bit
Function
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
XAnalog Module 1 - Input Channel 00 Warning
XAnalog Module 1 - Input Channel 01 Warning
XAnalog Module 1 - Input Channel 02 Warning
XAnalog Module 2 - Input Channel 00 Warning
XAnalog Module 2 - Input Channel 01 Warning
XAnalog Module 2 - Input Channel 02 Warning
XAnalog Module 3 - Input Channel 00 Warning
XAnalog Module 3 - Input Channel 01 Warning
XAnalog Module 3 - Input Channel 02 Warning
XAnalog Module 4 - Input Channel 00 Warning
XAnalog Module 4 - Input Channel 01 Warning
XAnalog Module 4 - Input Channel 02 Warning
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
