Chapter 8 Metering and Diagnostics
Analog Module 3
Analog Module 3 – Input Channel 00
Analog Module 3 – Input Channel 00 (Parameter 117) reports the monitored
value of Analog Module 3 – Input Channel 00.
Table 468 - Analog Module 3 – Input Channel 00 (Parameter 117)
Analog Module 3 – Input Channel 01
Analog Module 3 – Input Channel 01 (Parameter 118) reports the monitored
value of Analog Module 3 – Input Channel 01.
Table 469 - Analog Module 3 – Input Channel 01 (Parameter 118)
Analog Module 3 – Input Channel 02
Analog Module 3 – Input Channel 02 (Parameter 119) reports the monitored
value of Analog Module 3 – Input Channel 02.
Table 470 - Analog Module 3 – Input Channel 02 (Parameter 119)
Analog Module 3 Status
Analog Module 3 Status (Parameter 125) reports the status of Analog Module 3.
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
