Metering and Diagnostics Chapter 8
Table 465 - Analog Module 2 – Input Channel 01 (Parameter 115)
Analog Module 2 – Input Channel 02)
Analog Module 2 – Input Channel 02 (Parameter 113) reports the monitored
value of Analog Module 2 – Input Channel 02.
Table 466 - Analog Module 2 – Input Channel 02 (Parameter 116)
Analog Module 2 Status
Analog Module 2 Status (Parameter 124) reports the status of Analog Module 2.
Table 467 - Analog Module 2 Status (Parameter 124)
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Bit
Function
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
XInput Channel 00 Open Circuit
XInput Channel 00 Over Range
XInput Channel 00 Under Range
XInput Channel 01 Open Circuit
XInput Channel 01 Over Range
XInput Channel 01 Under Range
XInput Channel 02 Open Circuit
XInput Channel 02 Over Range
XInput Channel 02 Under Range
XOutput Channel 00 Open Circuit
XOutput Channel 00 Hold Last State Mode Active
XOutput Channel 00 Over Range
XOutput Channel 00 Under Range
XAnalog Module Configured
XAnalog Module Warning (Module Number Dial Changed)
XAnalog Module Faulted
