Rockwell Automation Allen-Bradley E300

88 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 4 System Operation and Configuration
User-defined Screen 3
User-defined Screen 3 – Parameter 1
User-defined Screen 3 - Parameter 1 (Parameter 432) is the E300 parameter
number to display for the first parameter in user-defined screen 3. You can select
one of the 560 available E300 Electronic Overload Relay parameters.
Table 59 - Screen 3 - Parameter 1 (Parameter 432)
User-defined Screen 3 – Parameter 2
User-defined Screen 3 - Parameter 2 (Parameter 433) is the E300 parameter
number to display for the second parameter in user-defined screen 3. You can
select one of the 560 available E300 Electronic Overload Relay parameters.
Table 60 - Screen 3 - Parameter 2 (Parameter 433)
User-defined Screen 4
User-defined Screen 4 – Parameter 1
User-defined Screen 4 - Parameter 1 (Parameter 434) is the E300 parameter
number to display for the first parameter in user-defined screen 4. You can select
one of the 560 available E300 Electronic Overload Relay parameters.
Table 61 - Screen 4 - Parameter 1 (Parameter 434)
Default Value 51
Minimum Value 0
Maximum Value 560
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 52
Minimum Value 0
Maximum Value 560
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 38
Minimum Value 0
Maximum Value 560
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
