Appendix C EtherNet/IP Information
Identity Object — CLASS CODE 0x0001
The following three instances of the Identity Object are supported:
Table 522 - Identity Object Instances
The following class attributes are supported for the Identity Object:
Table 523 - Identity Object Class Attributes
Instance 1 of the Identity Object contains the following attributes:
Table 524 - Identity Object Instance 1 Attributes
Instance Name Revision Attribute
1 Operating System Flash The firmware rev of the Control firmware stored in flash memory
2 Boot code Flash The firmware rev of the Boot Code stored in flash memory
3 Sensing Module The firmware rev of the Sensing Module firmware
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
Attribute ID Access Rule Name Data Type Value
1 Get Vendor UINT 1 = Allen-Bradley
2GetDevice TypeUINT 3
3 Get Product Code UINT 651
4Get
Revision
Major Revision
Minor Revision
Structure of:
USINT
USINT
Firmware revision of the Control firmware
5GetStatus WORD
Bit 0 – 0=not owned; 1=owned by master
Bit 2 – 0=Factory Defaulted; 1=Configured
Bits 4-7 – Extended Status (see Table 525
)
Bit 8 – Minor Recoverable fault
Bit 9 – Minor Unrecoverable fault
Bit 10 – Major Recoverable fault
Bit 11 – Major Unrecoverable fault
6 Get Serial Number UDINT unique number for each device
7Get
Product Name
String Length
ASCII String
Structure of:
USINT
STRING
“193-EIO Application”
8 Get State USINT See CIP Common Spec
9Get
Configuration
Consistency Value
UINT
16 bit CRC or checksum of all data included in the
following data sets:
Parameter included in the configuration assembly
MCC Object configuration data
DeviceLogix program data
Base Energy Object attribute 16
