Rockwell Automation Publication 193-UM015D-EN-P - February 2015 455
Specifications Appendix A
Low Voltage Directive
The E300 Electronic Overload Relay expansion digital modules are tested to
comply with EN60947-5-1 Low-voltage switchgear and controlgear Part 5-1:
Control circuit devices and switching elements.
Output Channels
Output ranges
Current: 0…20 mA, 4…20 mA
Voltage: 0…10V, 0…5V, 1…5V
Output Resolution 12 bits
Voltage Output Load 2k min. at 10V output (5 mA max.), including wire resistance
Current Output Load 50 minimum to 750 max
Output Impedance Current: >1M, Voltage: <1
Output Open Circuit detect
Current outputs: O.C. detect supported
Voltage outputs: O.C. detect not supported
Max Inductive Load
(current outputs)
0.1 mH
Max Capacitive Load
(voltage outputs)
1F
Table 511 - Thermistor/PTC Input Ratings (PTC only)
Terminals
IT1, IT2
Type of Control Unit
Mark A
Maximum Number of Sensors
6
Maximum Cold Resistance of PTC Sensor Chain
1500
Trip Resistance
3400 ± 150
Reset Resistance
1600 ± 100
Short-circuit Trip Resistance
25 ± 10
Maximum Voltage @ PTC Terminals (R
PTC
= 4 k)
7.5V DC
Maximum Voltage @ PTC Terminals (R
PTC
=open)
30V DC
Response Time
800 ms
Table 510 - Analog I/O Ratings (Expansion Analog Module)
Table 512 - Expansion Digital I/O Modules
Expansion Digital I/O Modules 193-EXP-DIO-42-24D 193-EXP-DIO-42-120 193-EXP-DIO-42-240
Digital Output Rated Operational Voltage (U
e
): 250V AC 250V AC 250V AC
Digital Output Rated Insulation Voltage (U
i
): 2000Vrms for 1s 2000Vrms for 1s 2000Vrms for 1s
Rated Impulse Withstand Voltage (U
imp
): N/A N/A N/A
Conditional Short Circuit Current: 1000 A 1000 A 1000 A
Recommended Control Circuit Fuse: KTK-R (6 A, 600V) KTK-R (6 A, 600V) KTK-R (6 A, 600V)
Utilization Category: AC15, DC13 AC15, DC13 AC15, DC13
Pollution Degree: 3 3 3
