56 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 3 Diagnostic Station
Parameter Group Navigation
To start the navigation menu, press the key. Use the or keys to
select the Groups navigation method and press .
Use the or keys to select the parameter group to display and press
.
Use the or keys to view the parameters that are associated with that
group.
When viewing a bit enumerated parameter, press to view the description of
each bit. Press to view the next bit. Press to return to the parameter.
Press to return to the parameter group navigation system.
