Metering and Diagnostics Chapter 8
Power Trip Status
Power Trip Status (Parameter 6) reports the status of the voltage-based protective
trip functions.
Table 360 - Power Trip Status (Parameter 6)
Control Trip Status
Control Trip Status (Parameter 7) reports the status of the control-based
protective trip functions.
Table 361 - Control Trip Status (Parameter 7)
Bit
1514131211109876543210 Function
X Under kW Trip
X Over kW Trip
X Under kVAR Consumed Trip
XOver kVAR Consumed Trip
XUnder kVAR Generated Trip
XOver kVAR Generated Trip
XUnder kVA Trip
XOver kVA Trip
X Under PF Lagging Trip
X Over PF Lagging Trip
X Under PF Leading Trip
X Over PF Leading Trip
Reserved
Reserved
Reserved
Reserved
Bit
1514131211109876543210 Function
XTest Trip
XPTC Trip
X DeviceLogix Trip
XOperator Station Trip
X Remote Trip
X Blocked Start Trip
X Hardware Fault Trip
X Configuration Trip
X Option Match Trip
X Feedback Timeout Trip
X Expansion Bus Trip
Reserved
Reserved
X Nonvolatile Memory Trip
X Test Mode Trip Enable
Reserved
