80 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 4 System Operation and Configuration
Output Pt00 Assignment (Parameter 202)
Output Pt00 Assignment (Parameter 202) allows you to assign this relay output
for the following functions:
Table 45 - Output Pt00 Assignment (Parameter 202)
V
a
l
u
e
A
ss
ign
m
en
t
D
es
cri
p
ti
on
0 Normal Function as a relay output
1Trip Relay
Function as a normally closed contact until the E300 is in a tripped state in which the relay opens. The Trip Relay
remains open until a trip reset is issued.
2Control Relay
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communications or via a DeviceLogix program. When the E300 enters into a tripped state
the Control Relay opens and remains open until a trip reset is issued.
3Trip Alarm
Function as a normally open contact until the E300 is in a tripped state in which the relay closes. The Trip Alarm
remains closed until a trip reset is issued.
4 Warning Alarm
Function as a normally open contact until the E300 is in a protection warning state in which the relay closes. The
Warning Alarm remains closed until the protection warning clears.
5 Monitor L1 Trip Relay
(1)
Function as a normally closed contact until the E300 is in a tripped state for a L1 Under Current, L1 Over Current, or
L1 Line Loss in which the relay opens. The Trip Relay remains open until a trip reset is issued.
6 Monitor L2 Trip Relay
(1)
Function as a normally closed contact until the E300 is in a tripped state for a L2 Under Current, L2 Over Current, or
L2 Line Loss in which the relay opens. The Trip Relay remains open until a trip reset is issued.
7 Monitor L3 Trip Relay
(1)
Function as a normally closed contact until the E300 is in a tripped state for a L3 Under Current, L3 Over Current, or
L3 Line Loss in which the relay opens. The Trip Relay remains open until a trip reset is issued.
8Monitor L1 Control Relay
(1)
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communications or via a DeviceLogix program. When the E300 is in a tripped state for a L1
Under Current, L1 Over Current, or L1 Line Loss, the relay opens. The Control Relay remains open until a trip reset is
issued.
9Monitor L2 Control Relay
(1)
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communications or via a DeviceLogix program. When the E300 is in a tripped state for a L2
Under Current, L2 Over Current, or L2 Line Loss, the relay opens. The Control Relay remains open until a trip reset is
issued.
10 Monitor L3 Control Relay
(1)
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communications or via a DeviceLogix program. When the E300 is in a tripped state for a L3
Under Current, L3 Over Current, or L3 Line Loss, the relay opens. The Control Relay remains open until a trip reset is
issued.
(1) Requires Control Module firmware v3.000 or higher
