Metering and Diagnostics Chapter 8
Output Status
Output Status (Parameter 18) reports the state of the relay outputs on the E300
Electronic Overload Relay Control Module and Digital Expansion Modules.
Table 368 - Output Status (Parameter 18)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
XOutput Pt00
XOutput Pt01
XOutput Pt02
X Digital Module 1 Output Pt00
X Digital Module 1 Output Pt01
X Digital Module 2 Output Pt00
X Digital Module 2 Output Pt01
X Digital Module 3 Output Pt00
X Digital Module 3 Output Pt01
X Digital Module 4 Output Pt00
X Digital Module 4 Output Pt01
Reserved
Reserved
Reserved
Reserved
Reserved
