Metering and Diagnostics Chapter 8
Trip / Warning History
The E300 Electronic Overload Relay provides a trip and warning history in
which the last five trips and last five warnings are recorded into nonvolatile
storage. A mask is available to limit which trip and warning events are logged to
the history's memory.
Trip History
When the E300 Electronic Overload Relay issue a trip, the reason for the trip is
recorded into the Trip History. Table 476
lists the codes that are available for the
trip history records.
Table 476 - Trip History Codes
Trip History Code Description
0 No Fault Conditions Detected
1 Motor current overload condition
2 Phase current Loss is detected in one of the motor phases
3 Power conductor or motor winding is shorting to ground
4 Motor has not reached full speed by the end of Stall Enable Time
5 Motor current has exceeded the programmed jam trip level
6 Motor current has fallen below normal operating levels
7 Phase to phase current imbalance detected
8 L1Current was below L1 Undercurrent Level longer than Trip Delay
9 L2Current was below L2 Undercurrent Level longer than Trip Delay
10 L3Current was below L3 Undercurrent Level longer than Trip Delay
11 L1 Current was over L1 Overcurrent Level longer than Trip Delay
12 L2 Current was over L2 Overcurrent Level longer than Trip Delay
13 L3 Current was over L3 Overcurrent Level longer than Trip Delay
14 L1 Current Lost for longer than the L1 Loss Trip Delay
15 L2 Current Lost for longer than the L2 Loss Trip Delay
16 L3 Current Lost for longer than the L3 Loss Trip Delay
17 Line to Line Under-Voltage condition detected
18 Line to Line Over-Voltage condition detected
19 Phase to phase voltage imbalance detected
20 The unit detects the supply voltage phases are rotated
21 Line voltage frequency is below trip level
22 Line voltage frequency has exceeded trip level
25 Sensing Module boot loader failed to load firmware
26 Sensing Module output enable open
27 Sensing Module missing interrupts
28 Sensing Module not calibrated
29 Sensing Module frame type failure
30 Sensing Module flash configuration failure
31 Sensing Module detected an overrun error
32 Sensing Module is not responding
33 Total Real Power (kW) is below trip level
34 Total Real Power (kW) has exceeded trip level
35 Under Total Reactive Power Consumed (+kVAR) condition detected
36 Over Total Reactive Power Consumed (+kVAR) condition detected
37 Under Total Reactive Power Generated (-kVAR) condition detected
