358 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 8 Metering and Diagnostics
38 Over Total Reactive Power Generated (-kVAR) condition detected
39 Total Apparent Power (VA or kVA or MVA) is below trip level
40 Total Apparent Power (VA or kVA or MVA) exceeded trip level
41 Under Total Power Factor Lagging (-PF) condition detected
42 Over Total Power Factor Lagging (-PF) condition detected
43 Under Total Power Factor Leading (+PF) condition detected
44 Over Total Power Factor Leading (+PF) condition detected
49 Test trip caused by holding the Test/Reset button for 2 seconds
50 PTC input indicates that the motor stator windings overheated
51 DeviceLogix defined trip was generated
52 The Stop button the Operator Station was pressed
53 Remote trip command detected
54 Maximum starts per hour exceeded
55 Hardware configuration fault. Check for shorts on input terminal
56 Invalid parameter config. See parameters 38-39 for details
58 DeviceLogix Feedback Timeout Trip was detected
59 Control Module CAN0 initialization failure
60 Control Module CAN0 bus failure
61 Control Module CAN1 initialization failure
62 Control Module CAN1 bus failure
63 Control Module ADC0 failure
64 Control Module detected too many CRC errors
65 Input Channel 00 on Analog Module 1 exceeded its Trip Level
66 Input Channel 01 on Analog Module 1 exceeded its Trip Level
67 Input Channel 02 on Analog Module 1 exceeded its Trip Level
68 Input Channel 00 on Analog Module 2 exceeded its Trip Level
69 Input Channel 01 on Analog Module 2 exceeded its Trip Level
70 Input Channel 02 on Analog Module 2 exceeded its Trip Level
71 Input Channel 00 on Analog Module 3 exceeded its Trip Level
72 Input Channel 01 on Analog Module 3 exceeded its Trip Level
73 Input Channel 02 on Analog Module 3 exceeded its Trip Level
74 Input Channel 00 on Analog Module 4 exceeded its Trip Level
75 Input Channel 01 on Analog Module 4 exceeded its Trip Level
76 Input Channel 02 on Analog Module 4 exceeded its Trip Level
77 External NVS Chip has detected communication timeout error
78 External NVS Chip has detected a CRC error
79 External NVS Chip has detected data out of range
81 Digital Expansion Module 1 is not operating properly
82 Digital Expansion Module 2 is not operating properly
83 Digital Expansion Module 3 is not operating properly
84 Digital Expansion Module 4 is not operating properly
85 Analog Expansion Module 1 is not operating properly
86 Analog Expansion Module 2 is not operating properly
87 Analog Expansion Module 3 is not operating properly
88 Analog Expansion Module 4 is not operating properly
90 Control Module installed does not match the expected type
91 Sensing Module installed does not match the expected type
92 Comms Module installed does not match the expected type
93 Operator Station installed does not match expected type
94 Digital Module installed does not match the expected type
Trip History Code Description
