Chapter 4 System Operation and Configuration
Digital I/O expansion module set to Digital Module 4. There are three different
types of Digital I/O expansion modules. Place the value of the expected Digital
I/O expansion module set to Digital Module 4 into Parameter 228. A value of (0)
disables the Option Match feature for this Digital I/O expansion module. A
value of (1), “No Digital I/O Expansion Module ”, makes the Digital I/O
expansion module set to Digital Module 4 not allowed on the Expansion Bus and
prevents you from connecting a Digital I/O expansion module set to Digital
Module 4 to the E300 Electronic Overload Relay system.
Table 32 - Digital I/O Expansion Module 4 Type (Parameter 228)
Analog I/O Expansion Module 1 Type (Parameter 229)
The E300 Electronic Overload Relay supports up to four additional Analog I/O
expansion modules. This parameter configures the Option Match feature for the
Analog I/O expansion module set to Analog Module 1. There is one type of
Analog I/O expansion module. Place the value of the expected Analog I/O
expansion module set to Analog Module 1 into Parameter 229. A value of (0)
disables the Option Match feature for this Analog I/O expansion module. A
value of (1), “No Analog I/O Expansion Module”, makes the Analog I/O
expansion module set to Analog Module 1 not allowed on the Expansion Bus and
prevents you from connecting an Analog I/O expansion module set to Analog
Module 1 to the E300 Electronic Overload Relay system.
Table 33 - Analog I/O Expansion Module 1 Type (Parameter 229)
Code Description Digital I/O Expansion Module Cat. No.
0Ignore —
1
No Digital I/O Expansion Module (Digital I/O Expansion
Module Not Allowed)
—
2 4 Inputs, 24V DC / 2 Relay Outputs 193-EXP-DIO-42-24D
3 4 Inputs, 110-120V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-120
4 4 Inputs, 220-240V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-240
Code Description Analog I/O Expansion Module Cat. No.
0 Ignore —
1
No Analog I/O Expansion Module (Analog I/O Expansion
Module Not Allowed)
—
2 3 Universal Analog Inputs / 1 Analog Output 193-EXP-AIO-31
