Commands Chapter 7
Clear Command
Clear Command (Parameter 165) allows you to clear historical logs, operating
statistics, and energy data within the nonvolatile memory of the E300 Electronic
Overload Relay.
Table 354 - Clear Command (Parameter 165)
298 Datalink7 0 425 OPFLeadWarnLevel 90 % 546 InAMod4C1TripLvl 0
426 DemandPeriod 15 Min 547 InAMod4C1WarnLvl 0
427 NumberOfPeriods 1 548 InAnMod4Ch02Type Disable
549 InAMod4Ch2Format Eng Units
550 InAMod4C2TmpUnit Degrees C
551 InAMod4C2FiltFrq 17 Hz
552 InAMod4C2OpCktSt Upscale
553 InAnMod4Ch2RTDEn 3-Wire
554 InAMod4C2TripDly 1.0
Second
s
555 InAMod4C2TripLvl 0
556 InAMod4C2WarnLvl 0
557 OutAnMod4Type Disable
558 OutAnMod4Select Ave %FLA
559 OutAnMod4FltActn Zero
560 OutAnMod4dlActn Zero
Number Parameter Name Default
Value
Units Number Parameter Name Default
Value
Units Number Parameter Name Default
Value
Units
Default Value 0 = Ready
Range 0 = Ready
1 = Clear Operating Statistics
2 = Clear History Logs
3 = Clear %TCU
4 = Clear kWh
5 = Clear kVARh
6 = Clear kVAh
7 = Clear Max kW Demand
8 = Clear Max kVAR Demand
9 = Clear Max kVA Demand
10 = Clear All
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units
