EtherNet/IP Information Appendix C
Instances 5 - 7 are available group 3 explicit message connections that are
allocated through the UCMM. The following attributes are supported:
Table 545 - Connection Object — CLASS CODE 0x0005 Instance 5…7 Attributes
The following services are implemented for the Connection Object.
Table 546 - Connection Object Services
Discrete Input Point Object — CLASS CODE 0x0008
The following class attributes are supported for the Discrete Input Point Object:
Table 547 - Discrete Input Point Object Class Attributes
Attribute ID Access Rule Name Data Type Value
1 Get State USINT
0=nonexistant
1=configuring
3=established
4=timed out
2 Get Instance Type USINT
0=Explicit
Message
3 Get Transport Class Trigger USINT 0x83 - Server, Transport Class 3
4 Get Produced Connection ID UINT
Depends on message group and Message
ID
5 Get Consumed Connection ID UINT
Depends on message group and Message
ID
6 Get Initial Comm Characteristics USINT 0x33 (Group 3)
7 Get Produced Connection Size UINT 0
8 Get Consumed Connection Size UINT
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get Watchdog Action USINT
01 = auto delete
03 = deferred delete
13 Get Produced Connection Path Length UINT 0
14 Get Produced Connection Path Empty
15 Get Consumed Connection Path Length UINT 0
16 Get Consumed Connection Path Empty
Service Code
Implemented for:
Service Name
Class Instance
0x05 No Yes Reset
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max. Instance UINT 22
