Rockwell Automation Allen-Bradley E300

312 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 8 Metering and Diagnostics
Input Status 0
Input Status 0 (Parameter 16) reports the state of the digital inputs on the E300
Electronic Overload Relay Control Module.
Table 366 - Input Status 0 (Parameter 16)
Input Status 1
Input Status 1 (Parameter 17) reports the state of the digital inputs on the E300
Electronic Overload Relay Digital Expansion Modules.
Table 367 - Input Status 1 (Parameter 17)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
XInput Pt00
XInput Pt01
XInput Pt02
XInput Pt03
XInput Pt04
XInput Pt05
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X Digital Module 1 Input Pt00
X Digital Module 1 Input Pt01
X Digital Module 1 Input Pt02
X Digital Module 1 Input Pt03
X Digital Module 2 Input Pt00
X Digital Module 2 Input Pt01
X Digital Module 2 Input Pt02
X Digital Module 2 Input Pt03
X Digital Module 3 Input Pt00
X Digital Module 3 Input Pt01
X Digital Module 3 Input Pt02
X Digital Module 3 Input Pt03
X Digital Module 4 Input Pt00
X Digital Module 4 Input Pt01
X Digital Module 4 Input Pt02
X Digital Module 4 Input Pt03
