508 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Appendix C EtherNet/IP Information
Table 533 - Instance 2 — Basic Overload Output Assembly from ODVA Profile
Table 534 - Instance 2 Attributes
Instance 50
The following table summarizes Attribute 3 Format:
Table 535 - Instance 50 — Basic Overload Input Assembly from ODVA Overload Profile
Table 536 - Instance 50 Attributes
Instance 120 - Configuration Assembly Revision 2
The following table shows Attribute 3 Format and Attribute 2 Member List for
revision 2 of the assembly.
Table 537 - Instance 120 — Configuration Assembly
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Fault Reset
Attribute ID Access Rule Member Index Name Data Type Value
1 Get Number of Members in Member List UINT 2
2Get
Member List Array of STRUCT
0
Member Data Description UINT 2
Member Path Size UINT 0
Member Path Packed EPATH
1
Member Data Description UINT 1
Member Path Size UINT 12
Member Path Packed EPATH 6BH and “Fault Reset”
3 Set Data UINT See data format above
4Get Size UINT1
100 Get Name SHORT_STRING “Trip Reset Cmd”
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Tripped
Attribute ID Access Rule Member Index Name Data Type Value
1 Get Number of Members in Member List UINT 1
2Get
Member List Array of STRUCT
0
Member Data Description UINT 1
Member Path Size UINT 8
Member Path Packed EPATH 67H and “Tripped”
3 Get Data UINT See data format above
4Get Size UINT1
100 Get Name SHORT_STRING “Trip Status”
INTDINT1514131211109876543210Size (bits)Param
0
0
ConfigAssyRev = 2 16 1100
1
SetOperatingMode 8 195
Reserved 8 1102
