Metering and Diagnostics Chapter 8
Power Warning Status
Power Warning Status (Parameter 12) reports the status of the control-based
protective warning functions.
Table 364 - Power Warning Status (Parameter 12)
Control Warning Status
Control Warning Status (Parameter 13) reports the status of the control-based
protective warning functions.
Table 365 - Control Warning Status (Parameter 13)
Bit
1514131211109876543210 Function
X Under kW Warning
X Over kW Warning
X Under kVAR Consumed Warning
XOver kVAR Consumed Warning
XUnder kVAR Generated Warning
X Over kVAR Generated Warning
XUnder kVA Warning
XOver kVA Warning
X Under PF Lagging Warning
X Over PF Lagging Warning
X Under PF Leading Warning
X Over PF Leading Warning
Reserved
Reserved
Reserved
Reserved
Bit
1514131211109876543210 Function
Reserved
X PTC Warning
X DeviceLogix Warning
X Operator Station Warning
Reserved
Reserved
Reserved
Reserved
X Option Match Warning
X Feedback Timeout Warning
X Expansion Bus Warning
X Number Of Starts Warning
X Operating Hours Warning
Reserved
Reserved
Reserved
